Stainless wire is used in a wide range of applications, such as wire mesh, conveyers, plumbing products and building exteriors. We offer an abundant variety of steel grades and qualities suitable for a diversity of applications, including such characteristics as high heat resistance, high corrosion resistance, high strength and nonmagnetic types, to best meet each customer's needs.
General JIS
| Steel grade | Wire diameter [mm] | Tensile strength [N/mm2] | Elongation (Reference) |
| SUS201, SUS304N1, SUH330 | 0.23〜0.50 (less than) | 680〜930 | More than 20 |
| 0.50〜1.60 (less than) | 650〜900 | More than 30 | |
| 1.60〜5.00 (less than) | 630〜880 | ||
| 5.00〜10.00 | 550〜800 | ||
| SUS303, SUS303Se, SUS303Cu, SUS304, SUS304L, SUS309S, SUS310S, SUS316, SUS316L, SUS316F, SUS317, SUS317L, SUS321, SUS347, SUSXM15J1 | 0.23〜0.50 (less than) | 610〜860 | More than 20 |
| 0.50〜1.60 (less than) | 570〜820 | More than 30 | |
| 1.60〜5.00 (less than) | 520〜770 | ||
| 5.00〜10.00 | 500〜750 | ||
| SUS201, SUS304N1, SUH330 | 0.23〜0.50 (less than) | 580〜830 | More than 20 |
| 0.50〜1.60 (less than) | 540〜790 | More than 30 | |
| 1.60〜5.00 (less than) | 500〜750 | ||
| 5.00〜10.00 | 490〜740 |
- *
- Please inquire about our ability to manufacture other sizes or for more detailed specifications.
| Steel grade | Wire diameter [mm] | Tensile strength [N/mm2] |
| SUS201, SUS303, SUS303Se, SUS303Cu, SUS304, SUS304L, SUS304N1, SUS304J3, SUS305, SUS305J1, SUS309S, SUS310S, SUS316, SUS316L, SUS316F, SUS317, SUS317L, SUS321, SUS347, SUSXM7, SUSXM15J1, SUS330 | 1.00〜1.60 (less than) | 780〜1130 |
| 1.60〜5.00 (less than) | 740〜1080 | |
| 5.00〜10.00 (less than) | 740〜1030 | |
| SUS403, SUS405, SUS410, SUS430 | 0.80〜5.00 (less than) | 540〜780 |
| 5.00〜10.00 (less than) | 490〜740 | |
| SUS410F2, SUS416, SUS420J1, SUS420J2, SUS420F, SUS420F2, SUS430F, SUS440C, SUH446 | 0.80〜1.60 (less than) | 640〜930 |
| 1.60〜5.00 (less than) | 590〜880 | |
| 5.00〜10.00 (less than) | 590〜830 |
- *
- Please inquire about our ability to manufacture other sizes or for more detailed specifications.
| Steel grade | Wire diameter [mm] | Tensile strength [N/mm2] |
| SUS201, SUS304, SUS304N1, SUS316 | 1.00〜1.60 (less than) | 1130〜1470 |
| 1.60〜5.00 (less than) | 1080〜1420 | |
| 5.00〜6.00 (less than) | 1030〜1320 |
- Remarks:
- Elongation values are not applicable for SUS303-W1, SUS303Se-W1, SUS303Se-W1 and SUS 316 F-W1.
- *
- Please inquire about our ability to manufacture other sizes or for more detailed specifications.
High corrosion resistance
Duplex stainless steel
This is a duplex type of stainless steel with mixed austenitic and ferritic structure.
This duplex type stainless steel wire has excellent corrosion resistance, higher than that of SUS316, along with higher strength than ordinary stainless steel wire. Moreover, because it is ferromagnetic, it can be used to help prevent debris intermixing caused by breakage, abrasion or other damage.
| Steel grade | Wire diameter [mm] | Tensile strength [N/mm2] |
| SUS329J3L, SUS329J4L | 2.00〜5.00 | 850〜1100 |
- *
- Please inquire about our ability to manufacture other sizes or for more detailed specifications.
